Panel Construction, Wiring & Test

From small user interface panels to large LV & HV power, process, control and automation cabinets, CableTronics offer a COMPLETE panel build service. This includes:-

In-house procurement or all parts or working from Free Issued materials.
Customized labelling, hardware assembly and wiring (windows, hangers, locks, fans, lights)
Machining, panel spraying and enclosure construction
Cabinet preparation (seals, glands, gaskets, grommets)
Mechanical mounting (trunking, DIN rail, earth bars, buzz bars)
Component population (connectors, screens, displays, PLCs, relays)
All internal point-to-point wiring and looming
Internal and external cable manufacture
Programming, calibration and set-up
PAT and high voltage testing

Panels with a few indicators and switches to cabinets incorporating screens, touch displays, PLCC controllers, MCBs, RCBs, heavy-duty switch gear, three-phase components, flow tubes, pressure gauges, valves and solenoids have all been built at our workshop in Biggleswade.

PANEL CONSTRUCTION

CableTronics constructs Panels and Control Boxes of varying complexity and sizes. Many must meet strict CE or UL regulations or comply with intrinsically safe standards. Others just a few components and a piece of DIN rail. Panel and cabinet building is about more than just the wiring. It often starts with machining and mechanical construction. Then, component placement, mounting and labelling. Followed by point-to-point and internal and external wiring. Finally, programming, set-up and test.

FOR MORE INFORMATION CLICK OR CALL 01767 600900

PANEL WIRING

At CableTroncs, meticulous attention is given to every production stage. Nothing is ever forced or strained; fasteners are correctly tightened, and exposed live components are always shrouded. Each wire is carefully labelled to identify every connection with enough excess left for re-work. Wiring is always neatly arranged. Components and graphic symbols can be identified with colour-coordinated labels or nameplates if required.

FOR MORE INFORMATION CLICK OR CALL 01767 600900

PANEL BUILD

Our experienced team ensures every panel meets industry standards for performance, reliability, and safety. Enclosures are made with top-quality materials that can withstand harsh conditions and meticulous attention is given to every production detail, such as:-
Planning, appearance and critical path routing.
Printed information, hinges and heat sources.
Seating, serviceability, support and stability.
Approach to termination points and termination lengths. Trunking, grouping, crimping and fastening.
Accessibility to test points.

FOR MORE INFORMATION CLICK OR CALL 01767 600900

PANEL TESTING

CableTronic's procedures and processes are monitored by ISO and "UL" accredited bodies. Continuous internal and external audits ensure 100% compliance with our customer's drawings, bills of materials, parts list and instructions. Full traceability of parts from supplier to product is maintained using our Cim50 MRP manufacturing software, and all Labour and Tooling are recorded and kept on file for historical reference. Various continuous improvement programmes are implemented as part of our quality system. A QDIP system is often employed for larger assembly projects. Inspections occur throughout the assembly process from Goods-In to dispatch, with line/cell spot checks when and where required.

FOR MORE INFORMATION CLICK OR CALL 01767 600900

Below are some of the more popular manufacturers we purchase from:

Our panels and cabinets are used in a vast array of applications, including public areas, process control, machine automation, fire and security, gas pipelines, petrol forecourts, transportation and aviation systems around the world.

Speak to us about Panel Construction, Wiring & Test
